Product Description
The AP20 Mini sets a new standard in super energy efficient heating and cooling. The AP20 is NZ’s smallest high wall indoor unit and starting at a whisper quiet 21dBA, it’s the perfect solution for bedrooms, home offices and hallways! With Dual Barrier Coating that prevents dust and dirt build-up on the inner surface, the Classic AP20 stays clean year-round; maximising efficiency and home comfort.
Cooling
Capacity
2.0 kW
Heating
Capacity
2.5 kW
- Description
- Additional information
- Specifications
- Downloads
- Support
Description
NZ’s Smallest High Wall Indoor Unit
Specifically designed where space is at a premium the 760mm wide foot print makes it ideal for positioning above doorways in bedrooms, home offices and in hallways. Now smaller spaces no longer need to miss out on year round comfort. Pint sized but big on performance, the AP Mini is packed with features that maximise energy efficiency.
*Indoor unit total volume size of 0.034m3
Whisper Quiet
Starting from barely a whisper, the AP Series ensures you only feel the warmth, not hear it! Furthermore, the addition of Night Mode means the outdoor operating noise level drops by a further 3dBA – for the perfect night’s sleep.
Dual Barrier Coating
The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit; keeping your heat pump clean year-round. Keeping key internal components like the heat exchanger, fan and internal duct clean is important for both home comfort and efficiency. Not only does dust and dirt build-up typically create unpleasant odours, it also forces a heat pump to work harder, which can result in significantly impaired energy efficiency.
Next Generation R32 EcoCore Technology
R32 is a refrigerant with just one-third the global warming potential of R410A and has zero ozone depletion potential. R32 offers increased energy efficiency, and is said to be the next generation of refrigerants.
Washable Air Purifying Filter
The AP Mini Series is equipped with an Air Purifying Filter. This washable filter traps particles such as dust, pollen and other airborne contaminants, generating stable antibacterial and deodorising effects. The size of the three-dimensional surface has been increased from previous models, enlarging the filter capture area. These features give the Air Purifying Filter better dust collection performance than conventional filters.
Horizontal Airflow
The AP Series eliminates uncomfortable draughts with horizontal airflow in cooling mode, by first spreading airflow evenly across the ceiling.
Blue Fin Condenser
The heat exchanger of the outdoor has been treated with Blue Fin anti-corrosion treatment slowing the corrosion process caused by salt and sulphur in the air especially in coastal and high sulphur areas.
Night Mode
For the perfect night’s sleep; dimming the operation indicator light, disabling any beeping from the unit, and lowering the outdoor operating noise level by 3dBA.
Optional Wi-Fi Control Upgrade
With the addition of award-winning Mitsubishi Electric Wi-Fi Control, you can control and monitor your heat pump from absolutely anywhere via your smartphone, tablet or online account.
Additional information
| Controller Type | Advanced Wi-Fi Control, Wireless Weekly Remote |
|---|
MSZ-AP20VGD // AP20 Mini High Wall Heat Pump System
| · | Function: Cooling/Heating | · | Type: Single Split, Inverter |
| Rated | |||
| · | Capacity – Cooling: 2.0 kW | · | Capacity – Heating: 2.5 kW |
| · | Capacity – Cooling (min. – max.): 0.6 – 2.7 kW | · | Capacity – Heating (min. – max.): 0.5 – 3.5 kW |
| · | Power Input – Cooling: 0.46 kW | · | Power Input – Heating: 0.6 kW |
| · | Current – Cooling [In+Outdoor] (Rated): 2.60 A | · | Current – Heating [In+Outdoor] (Rated): 3.20 A |
| Energy Rating Residential | |||
| · | ZERL – Cooling (Cold/Mixed/Hot): 3.5 / 3.5 / 3.5 | · | ZERL – Heating (Cold/Mixed/Hot): 2.0 / 2.5 / 3.0 |
| · | TCSPF (Cold/Mixed/Hot): 5.29 / 5.15 / 5.50 | · | HSPF (Cold/Mixed/Hot): 3.94 / 4.28 / 4.61 |
| · | EER / COP: 4.35 / 4.17 | · | AEER / ACOP: 4.31 / 4.14 |
| Energy Rating Commercial | |||
| · | TCSPF (Cold/Mixed/Hot): 6.24 / 5.88 / 5.84 | · | HSPF (Cold/Mixed/Hot): 4.10 / 4.40 / 4.60 |
| Performance | |||
| · | Operation Range – Cooling: -10 / +46 degC | · | Operation Range – Heating: -15 / +24 degC |
MSZ-AP20VGD-A1 – Wall Mounted Classic AP20 Indoor Unit – White
| · | Function: Cooling/Heating | · | Type: Single Split, Inverter |
| Nominal Capacity | |||
| · | Capacity – Cooling: 2.0 kW | · | Capacity – Heating: 2.5 kW |
| · | Sound Level – Cooling (Low – Super High, dB(A)): 21 / 26 / 30 / 35 / 42 | · | Sound Level – Heating (Low – Super High, dB(A)): 21 / 26 / 30 / 35 / 42 |
| · | Air Volume – Cooling (Super High, Litre/sec): 115 | · | Air Volume – Heating (Super High, Litre/sec): 122 |
| · | Refrigerant: R32 | · | Liquid Pipe Size (OD, mm): 6.35 |
| · | Gas Pipe Size (OD, mm): 9.52 | · | Max. Pipe Length (m): 20 |
| · | Max. Pipe Height (m): 12 | · | Power Supply: 230V / Single Phase / 50/60 Hz |
| · | Dimensions (WxDxH, mm): 760 x 178 x 250 | · | Weight: 8.2 kg |
MUZ-AP20VGD-A1 – R32 Inverter Outdoor Unit
| · | Function: Cooling/Heating | · | Type: Single Split, Standard Inverter |
| · | Operation Range – Cooling: -10 / +46 degC | · | Operation Range – Heating: -15 / +24 degC |
| · | Sound Level – Cooling (dB(A)): 47 | · | Sound Level – Heating (dB(A)): 48 |
| · | Air Volume – Cooling (Litre/sec): 115 | · | Air Volume – Heating (Litre/sec): 122 |
| · | Power Supply: Single phase, 230 V, 50/60Hz | · | Refrigerant: R32 |
| · | Liquid Pipe Size (OD, mm): 6.35 | · | Gas Pipe Size (OD, mm): 9.52 |
| · | Max. Pipe Length (m): 20 | · | Max. Pipe Height (m): 12 |
| · | Dimensions (WxDxH, mm): 800 x 285 x 550 | · | Weight (kg): 31 |
· Rating Conditions (AS / NZS 3823):
Cooling – Indoor: 27°C DB, 19°C WB. Outdoor: 35°C DB. Heating – Indoor: 20°C DB, Outdoor: 7°C DB, 6°C WB.
· Sensible Cooling Conditions, Indoor: 27°C DB, 20°C WB. Outdoor: 35°C DB.
· Dry function will not work when the room temperature is below 13°C.
· Colour: Heat pump units shown may not be colour accurate, please ensure you view an actual unit for colour matching.
· Maximum length is inclusive of height differential. i.e. (20m length/12m high) means the pipe can be 12m high and 8m across for a total length of 20m.
· Measure of Energy Efficency: A calculated measurement of energy efficiency for both heating and cooling using the ratio of kW input to kW output.
EER = Energy Efficiency Ratio
COP = Coefficient of Performance
AEER# = Annual Energy Efficiency Ratio
ACOP# = Annual Coefficient of Performance
#These include standby power in the rating calculation
· Star Ratings based on the Seasonal Energy Rating standard for New Zealand – cold zone [GEMS 2019]
MSZ-AP20VGD-A1
